LTR-7 Z
The Enervent LTR-7 unit is best suited for large detached houses and public spaces, such as schools and kinder gardens.
The LTR-series units are designed for installation in the roof, in the attic, in a false ceiling or in a technical space. The horizontal installation often saves a lot of space. LTR-series units are well insulated and can be installed in cold places. The unit needs additional insulation if the temperature around it drops below -10°C.
The simple but ingenious structure and the low pressure drop of the unit ensure an inexpensive and safe operation.
Enervent LTR-7 units are ‘non-residential ventilation units’ (NRVU) according to the EU Commission Regulation No 1253/2014. Ventilation units with maximum flow rate over 250 m3/h which the manufacturer has not declared intended as being exclusively for a residential ventilation application are called non-residential. Non-residential ventilation units (NRVUs) are excluded from EcoDesign labelling.
Our calculation software Energy Optimizer, reports whether the chosen NRVU unit fulfills the EcoDesign requirements or not for the intended project.
Duct connections
The LTR-7 Z unit can be installed either with the hatch upwards or to the side. When installing the unit with the hatch to the side, it can be placed on either side. It is not allowed to install the unit with the hatch downwards or standing upright with the duct connections vertically.
Control options
 eAir |  eWind | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Fan speed settings | Through operation modes | 4-step | |||||||
| Supply air temperature set point | |||||||||
| Control of electrical after heater | |||||||||
| Over pressure mode | |||||||||
| Alarm and maintenance reminder | |||||||||
| Humidity boosting | |||||||||
| Possibility to connect two panels to one unit | |||||||||
| Cooling recovery | Automatic | Automatic | |||||||
| KNX connectivity | |||||||||
| Commissioning parameters view | |||||||||
| On-off control for CHG brine pump | |||||||||
| On-off control for GWC damper motor | |||||||||
| Control for CHG coil 3-way valve motor | |||||||||
| Exercising of brine pumps during standby | |||||||||
| Exercising of the HRW during standby | |||||||||
| Modbus RTU | |||||||||
| Modbus TCP/IP | |||||||||
| Stepless control of heat recovery | |||||||||
| Control of damper motors | |||||||||
| Control of electrical pre-heater | |||||||||
| Control of water pre-heater/cooler | |||||||||
| Control of water heater | |||||||||
| Eco mode | |||||||||
| Control of water cooler | |||||||||
| Boosting function | |||||||||
| Measurements view | |||||||||
| Carbon dioxide boosting | |||||||||
| Time programs | |||||||||
| Summer night cooling | |||||||||
| Temperature boosting | |||||||||
| Compensation for hood/central vacuum cleaner | |||||||||
| Constant duct pressure mode | |||||||||
| Internet user interface | |||||||||
| Time extension mode | |||||||||
| Setup wizard | |||||||||
| Show more features | |||||||||
| Show less features | |||||||||
This feature is always included
This feature is available with extra equipment
Datasheet
Brochures
Models
| Product number | Unit |
|---|---|
| P04 214 0002 | LTR-7 Z eAir E |
| P04 214 0003 | LTR-7 Z eAir E-CG |
| P04 214 0006 | LTR-7 Z eAir W |
| P04 214 0007 | LTR-7 Z eAir W-CG |
| P04 304 0002 | LTR-7 Z eWind E |
| P04 304 0003 | LTR-7 Z eWind E-CG |
| P04 304 0006 | LTR-7 Z eWind W |
| LTR-7 Z RL E | |
| LTR-7 Z RL E-CG | |
| LTR-7 Z RL W | |
| LTR-7 Z RL W-CG |
